How Radio Waves Travel Through the Atmosphere

Treat the atmosphere as empty space and your radar predictions will be off by miles. The air itself is part of every radar system.

How Radio Waves Travel Through the Atmosphere
tech · physics

Refraction and the 4/3 earth

The atmosphere's density decreases with height, which slightly bends radio waves downward. Radar engineers approximate this by pretending the earth has a radius 4/3 of its real value. With this trick, signals travel in straight lines on charts and ranges work out correctly.

Ducting

Strong temperature inversions over water can trap radio waves in a layer near the surface. Ships sometimes detect targets at 500 km — far beyond line-of-sight — because the duct acts like a waveguide. Air-defence systems both exploit and curse this effect.

▒ open the radar — lock the signals
▸ Play Signal//Lock now

Atmospheric absorption

Water vapour and oxygen absorb specific frequencies. The 22 GHz water peak and 60 GHz oxygen peak are nearly opaque. Mobile networks place 5G near 28 and 39 GHz precisely to avoid those peaks; military satellites use 60 GHz precisely to hide in them.

Rain attenuation

At X-band, heavy rain can cut range by half. At Ka-band it can cut range to a few kilometres. This is why automotive radars are dual-mode and why weather radars deliberately operate at lower frequency.
